Used Amada 3" Circular Carbide Saw Model CM 75 CNC Star

Listing description

Specifications:

- Type: Saws, Cold & Carbide
- Model: CMB-75 CNC
- Brand: AMADA
- Condition: Like New
- Year: 2018

Description:

- Cutting capacity round: 0.394" - 3.0"
- Cutting capacity rectangle (W x H): 0.394" x 0.394" - 2.36" x 2.36"
- Saw blade speed: 56 - 197 RPM (BY INVERTER)
- Saw blade motor: 10 HP
- Hydraulic pump motor: 2 HP
- Cut-to-length feed motor: 1 H.P. servo motor
- Index stroke: 28.1" (max stroke with multi index 472.44")
- Remnant length: 0.98" (plus index length)
- Machine dimensions: 287.7"L x 84"W x 63.4"H
- Machine weight: 5,918 Lbs.

Equipped with:

- 45 degree heavy-duty sliding head design on linear rails
- 15'6" inclined loading table
- AC servo motor & ball screw material index
- Automatic material dependent cutting speed control
- Chip conveyor
- Variable vise pressure
- High precision auto sizing
- Servo controlled precision gripper
- High speed feeder gripper
- Electromagnetic braking system
- Automatic cut & remnant sorter
- Color touchscreen display

Machine sold As-Is Where-Is

This equipment is located in US
